Cabin Air Spring for Navistar Trucks
TR7108 Cabin Air Spring for Navistar / International Trucks TR7108
Air Spring Type
Cabin Air Spring
BCR
7.75
Top Plate Diameter
2.84
Piston Diameter
2.90
Bellows Diameter
2.90
Piston Height
1.48
Piston Material
Composite
Max Extended Height
9.75
Minimum Compressed Height
2.40
Air Inlet Type
Female
Top Plate Mounting Type
Threaded Hole
Top Plate Threaded Hole Quantity
2
Distance Between Top Plate Threaded Holes
0.75
Piston Mounting Type
Threaded Hole
Piston Threaded Hole Quantity
1
Has Inner Bumper
No
Bellows Number
YELLOW
| Navistar IHC: | 2500012C1, 2507756C1 |
| Link Manufacturing: | 1102-0075 |
| Firestone: | W02-358-7108 |
| Goodyear: | 1S5-057 |
| Contitech: | SZ70-8077P02 |
| Extended Height: | 9.75" |
| Compressed Height: | 2.40" |
| BCR: | 7.75" |
